Start Capacitor Run Capacitor Motor Capacitor CBB65 Air Conditioner Capacitor
Being a supplier in the film capacitor industry,we have become the reliable manufacturer
and supplier of capacitors.Reliable and economical, our offered capacitor is available in
various specifications to cater specific demand of our clients.Compact in design,the offered
capacitor is carefully designed using best in class components and modish technology in
order to ensure its utmost quality.These capacitors are available at valuable price for our
precious clients.
1. Applications
(1) CBB65 capacitor applied to Air Conditioner,Compressors,AC Motor,General Purpose,
Refrigerator,Lighting,Power,High Voltage,etc;
(2) CBB65 Capacitor broadly applied to starting and running of AC single-phase motors
at 50Hz/60Hz frequency for family air conditioners and high power illuminators for the
sake of power factor compensation.
2. Specifications
Note:The Composite Capacitor can be also customized producing according
to our customer's request.
3. Dimensions(mm)
Note:Other specifications,size,terminal outside table and price are negotiable.
4. Production Process
The CBB65 AC Motor Capacitor adopts zinc-aluminum edge thickened metallized polypropylene
film as the electrode and the dielectric. It is tightly rolled by high speed winding machine, sealed
by aluminum shell, and impregnated with refined castor oil at high temperature to keep it in
a vacuum state. Therefore, the capacitor can be more stable, longer life.What's more,it adopted
the second generation of mechanical explosion-proof design, so the reliability is very higher.
It is suitable for the frequency of 50Hz/60Hz ac single phase motor starting and operating power.
Besides, it also suitable for high power lighting lamps and lanterns of power factor compensation.
5. Qualification Certification
6. Production Equipments
7. Patents And R&D
8. Honors Our Team Has Received
9. Our Team Activities
10. Customer Question And Answer
Why Choose us?
(1)Leading Technology
3 High-vacuum coating machines,14 high-speed slitting machines,7 winding machines
and other automatic equipments;Professional manufacturing film capacitors for decades;
Various patents.
(2)High Quality Products
Constantly updating high-precision equipments;Advanced equipments with
professional technicians;High grade materials; Quality management service center;
(3)Fast Response And Delivery
7×24 Hours online for any questions;3-7 days after payment according to quantities,
can adjust the flexible delivery time according to customer demand.
(4)Free Sample
We can provide a certain amount of free samples according to customer's requirement.
There is no best product, only the most suitable products!
Being a supplier in the film capacitor industry,we have become the reliable manufacturer
and supplier of capacitors.Reliable and economical, our offered capacitor is available in
various specifications to cater specific demand of our clients.Compact in design,the offered
capacitor is carefully designed using best in class components and modish technology in
order to ensure its utmost quality.These capacitors are available at valuable price for our
precious clients.
1. Applications
(1) CBB65 capacitor applied to Air Conditioner,Compressors,AC Motor,General Purpose,
Refrigerator,Lighting,Power,High Voltage,etc;
(2) CBB65 Capacitor broadly applied to starting and running of AC single-phase motors
at 50Hz/60Hz frequency for family air conditioners and high power illuminators for the
sake of power factor compensation.
2. Specifications
| Technical Specifications | |
| Model No. | CBB65 Capacitor |
| Type | Air Conditioner Capacitor |
| Structure | Single Capacitor |
| Manufacturing Material | Metallized Polypropylene Film |
| Electrolyte | Polypropylene Film |
| Reference Standards | GB/T 3667.1(IEC60252-1) |
| Climatic category | 40/70/21,40/85/21 |
| Class of operation | Class B(10000h) Class C(3000h) |
| Class of safety production | S2 |
| Voltage range | 220VAC 370VAC 440VAC 450VAC |
| Capacitance range | 2uF~100uF |
| Capacitance tolerance | ±5% ±10% ±15% |
| Dissipation factor | 20*10-4(100Hz,20ºC) |
| Test voltage terminal to terminal UTT | 2 Un for 2 seconds |
| Test voltage terminal to case UTC | (2 Un+1000)VAC or 2000VAC-50Hz for 60 seconds |
| Insulation Resistance | ≥3000MΩ.uF(100Hz,20ºC,1min) |
| Altitude | ≤2000m |
| Remain voltage when put into operation | No more than 10% of rated voltage |
| Maximum allowed voltage | No more than 1.1 times rated voltage |
| Maximum allowed current | No more than 1.3 times rated current |
| Package Type | Export Standard Carton for CBB65 Capacitor |
| Production Capacity | 3500,000PCS/Month |
| MOQ | 1PCS |
| Size | Negotiable |
to our customer's request.
3. Dimensions(mm)
| No | Specifications | Terminal | Size |
| 1 | CBB65-450VAC 2μF ~9μF | 2×4 or 2×2 pin | Φ40×60 |
| 2 | CBB65-450VAC-10μF | 2×4 or 2×2 pin | Φ40×60 |
| 3 | CBB65-450VAC-12.5μF | 2×4 or 2×2 pin | Φ40×70 |
| 4 | CBB65-450VAC-15μF | 2×4 or 2×2 pin | Φ45×70 |
| 5 | CBB65-450VAC-20μF | 2×4 or 2×2 pin | Φ45×75 |
| 6 | CBB65-450VAC-25μF | 2×4 or 2×2 pin | Φ50×85 |
| 7 | CBB65-450VAC-30μF | 2×4 or 2×2 pin | Φ50×100 |
| 8 | CBB65-450VAC-35μF | 2×4 or 2×2 pin | Φ50×100 |
| 9 | CBB65-450VAC-40μF | 2×4 or 2×2 pin | Φ50×100 |
| 10 | CBB65-450VAC-45μF | 2×4 or 2×2 pin | Φ50×100 |
| 11 | CBB65-450VAC-50μF | 2×4 or 2×2 pin | Φ50×125 |
| 12 | CBB65-450VAC-55μF | 2×4 or 2×2 pin | Φ50×125 |
| 13 | CBB65-450VAC-60μF | 2×4 or 2×2 pin | Φ50×125 |
| 14 | CBB65-450VAC-65μF | 2×4 or 2×2 pin | Φ55×125 |
| 15 | CBB65-450VAC-70μF | 2×4 or 2×2 pin | Φ55×125 |
| 16 | CBB65-450VAC-80μF | 2×4 or 2×2 pin | Φ60×125 |
| 17 | CBB65-450VAC-90μF | 2×4 or 2×2 pin | Φ60×125 |
| 18 | CBB65-450VAC-100μF | 2×4 or 2×2 pin | Φ63.5×125 |
4. Production Process
The CBB65 AC Motor Capacitor adopts zinc-aluminum edge thickened metallized polypropylene
film as the electrode and the dielectric. It is tightly rolled by high speed winding machine, sealed
by aluminum shell, and impregnated with refined castor oil at high temperature to keep it in
a vacuum state. Therefore, the capacitor can be more stable, longer life.What's more,it adopted
the second generation of mechanical explosion-proof design, so the reliability is very higher.
It is suitable for the frequency of 50Hz/60Hz ac single phase motor starting and operating power.
Besides, it also suitable for high power lighting lamps and lanterns of power factor compensation.
5. Qualification Certification
6. Production Equipments
7. Patents And R&D
8. Honors Our Team Has Received
9. Our Team Activities
10. Customer Question And Answer
Why Choose us?
(1)Leading Technology
3 High-vacuum coating machines,14 high-speed slitting machines,7 winding machines
and other automatic equipments;Professional manufacturing film capacitors for decades;
Various patents.
(2)High Quality Products
Constantly updating high-precision equipments;Advanced equipments with
professional technicians;High grade materials; Quality management service center;
(3)Fast Response And Delivery
7×24 Hours online for any questions;3-7 days after payment according to quantities,
can adjust the flexible delivery time according to customer demand.
(4)Free Sample
We can provide a certain amount of free samples according to customer's requirement.
There is no best product, only the most suitable products!
